Part No.

Frequency Range ( Hz )

Passband Loss ( dB )

Passband Standing Wave

Out Of Band Suppression

Volume ( mm ³)

BKLJZ-610-670M

610～670M

1.0

1.3:1

>70dB@570,710MH z

180x66x2 1

BKLJZ-710-770M

710～770M

1.0

1.3:1

>70dB@670,810MH z

180x66x2 1

BKLJZ-1000- 1500M

1000 ～1500M

1.0

1.6:1

>20dB@960MHz

160x38x1 8

BKLJZ-1200- 2000M

1200～2000M

1.0

1.6:1

>55dB@1000,2400M Hz

58x32x12

BKLJZ-2000- 3600M

2000～3600M

1.0

1.6:1

>55dB@1800,4000M Hz

73x22x13

BKLJZ-3600- 6000M

3600～6000M

1.0

1.6:1

>55dB@3000,6960M Hz

64x16x11

BKLJZ-6000- 8400M

6000～8400M

1.0

1.6:1

>50dB@12GHz

70x14x11

BKLJZ-12-18G

12 ～18G

1.0

1.6:1

>50dB@9,19GHz

80x13x9

BKLJZ-2-4G

2～4G

0.4

1.3:1

>35dB@1.25GHz

35x35x7.2

BKLJZ-4-8G

4～8G

0.5

1.3:1

>35dB@3.10GHz

40x25x7.2
