Function pattern

Model

frequency (MHZ)

passband loss

Insert oss (dB,max.)

Insulation（dB,min.)

Range / phase balance (±dB/°, max.)

Standing wave (max.)

Size and ports (mm)

Other

Route 2

BKHFT1127- *

1.5~30

600

0.3

25

-/3^

1.25

100×100×40 port ： N

--

BKHFT1128- *

10~100

10

0.25

20

0.2/-

1.25

40×40×25 ports: SMA

--

4 road

BKHFT1129- *

20~200

1.8k

0.5

15

0.2/-

1.25

213×238×57   distribution   port:   N synthesis port: SC

--

BKHFT1130- *

30~110

3k

0.5

18

-/5°

1.35

235×210×68; Port: SC

1. Cooling mode:air cooling

2.Temperature

control:85℃

BKHFT1131- *

3~28

50

0.25

20

-/3°

1.25

130×60×60 port: SMA

--

BKHFT1132- *

3~28

6k

0.3

20

-/3°

1.25

482.6 x 177.8 x 570 port: L29

1. Cooling mode:air cooling

2.Temperature control:85℃

No.8

BKHFT1133- *

4~30

50

0.3

20

-/3°

1.25

120×60×20 port: SMA-K

--
